The vehicle features a completely new design with high distinctiveness, featuring a fashionable black background with a large brand logo. The LED headlights have sharp, defined edges, and the aluminum alloy roof trim provides a three-dimensional appearance. With its double-wishbone independent suspension, four-wheel hydraulic disc brakes, and electronic auto-parking features, the performance is exceptional.
**Widely used in golf communities, tourist attractions, resort hotels, exhibition centers, large industrial parks, airports, and other large public venues.*
The RG-122 Golf Cart features a high-efficiency 48V AC motor system, delivering exceptional power output and extended range. Designed for golf courses, resorts, scenic areas, and hospitality environments, it offers a stylish appearance and a smooth, comfortable driving experience, ideal for various premium applications.
Key Features:
Powerful Drive System: Equipped with a high-performance 48V AC asynchronous motor, ensuring excellent climbing ability and long-lasting stable power.
Extended Range: High-capacity battery pack, offering a single-charge driving range of 80–100 km.
Advanced Control System: Uses intelligent controller technology to improve energy management and driving safety.
Comfort-Focused Design: Ergonomically designed seats and premium suspension system provide a smooth and enjoyable ride.
Comprehensive Safety Configuration: Standard with hydraulic braking system, LED headlights, rearview mirrors, and seat belts for complete driving protection.
Eco-Friendly and Energy-Efficient: Zero emissions and low-noise operation, promoting a greener environment.
Technical Specifications:
Motor Type: 48V AC asynchronous motor
Rated Power: 5kW (customizable upon request)
Battery Type: Deep-cycle maintenance-free lead-acid battery / Optional lithium battery
Top Speed: 25–40 km/h (adjustable)
Seating Capacity: 2–4 seats (optional)
Charging Time: 6–8 hours
Tire Size: 18×8.5-8 vacuum tires
Dimensions: Approximately 2700mm × 1200mm × 1800mm (subject to actual model)
Applications:
Golf Courses
Scenic Area Transportation
Resort Patrol and Guest Transport
Real Estate Showcases
Parks and Campus Mobility
| Parameter and Configuration | RG122 | |
| Dimension：L*W*H | 2930mm*1390mm*2030mm | |
| Technical Parameters | Rated Passenger Capacity | 4 |
| Driving system | 2WD/4WD switchable drivetrain | |
| Maximum Speed | U.S. 25 miles/h (Europe 30 km/h) | |
| Braking Distance | ≤3.5m | |
| Wheelbase | 2050 | |
| Front and Rear Track Width | 925/1000 | |
| Minimum Ground Clearance | 170 | |
| Maximum Climbing Gradient | 40%(≈21.8) | |
| Minimum Turning Radius | 3.5m | |
| Curb Weight(including lithium battery) | 460kg | |
| Driving Range | ≧50mile（on level ground） | |
| Electric System | Controller | Yingboer48V-400A(optional:Curtis Toyota ) |
| Lead-Acid Battery | 48V 150AH | |
| Lithium iron phosphate | 48V 150AH(Optional)60V 150AH | |
| Electric Motor | full closed-loop control AC asynchronous motor,33V5kW | |
| Charger | Charger: U.S. 48V 13A/110V, Europe 48V 25A/220V (Charging time: 8-10 hours) | |
| DC Converter | Non-isolated DC Converter 48V/12V-300W | |
| Display Screen | 10.1-inch LCD IP66 waterproof multimedia combination instrument, with radio, MP5, bluetooth music, bluetooth phone, vehicle diagnostic function | |
| Body Configuration | Front Windshield | DOT-certified anti-rollover acrylic glass
Optional: DOT-certified tempered glass + wiper |
| Floor | Sandblasted aluminum alloy non-slip floor | |
| Body Frame | Adopts a lightweight, high-strength trapezoidal frame design, with electrophoretic coating on the surface, | |
| Steering System | Bidirectional rack-and-pinion steering system with automatic gap compensation | |
| Brake System | Dual-circuit four-wheel hydraulic brakes, four-wheel disc brakes + electronic parking brake | |
| Front Axle and Suspension | Double wishbone independent suspension, coil springs + hydraulic shock absorber | |
| Rear Axle and Suspension | Integral rear axle with a gear ratio of 12.3:1, C-type frame trailing arm+coil spring shock absorbers+simple hydraulic shock absorbers+and stabilizer bar | |
| Tire Diameter | Tires: 23-10.5-12, 12-inch aluminum alloy wheels | |
